Dimensions
ROOF MOUNTING SPACE:
Width - (number of panels x 27") + 24"
Length - Panel Length + 24"
RACK SPACE:
Width - (number of panels x 27") + 2"
Length - Panel Length + 6"
Weight
Without water - 22 lbs or .49 lbs./ft²
Full of Water - 31 lbs. or .85 lbs./ft²
Chemical Resistance
Compatible with common collector fluids
Weatherability
Weatherometer, accelerated outdoor exposure, and other
extensive laboratory testing demonstrates long-term weatherability of
solar collectors (refer to warranty).
Absorptivity
0.96
Emissivity
0.90
Drainback Tank
DIMENSIONS:
33in. x 18in. x 5in.
CAPACITY:
10 gallons
WEIGHT:
up to 80 lbs when water is at full mark
Circulation Module
DIMENSIONS:
11in. x 11in. x 9in.
WEIGHT:
Up to 20 lbs when plumbing lines are full of water.
VOLTAGE:
120 Volts, 1.2 amps
........
....
..................
.......................
